Single Mode 0.9mm lc MPO To SC Mtp Fanout Cable 0.5m 12 Fiber

Name: Single Mode 09mm lc MPO To SC Mtp Fanout Cable 05m 12 Fiber
Brand: FONGKO
Price: 1 USD

Buy cheap Single Mode 0.9mm lc MPO To SC Mtp Fanout Cable 0.5m 12 Fiber product

Model Number : FKPAT-021

Place of Origin : China

Brand Name : FONGKO

MOQ : 10 Pieces

Price : Negotiatable

Type : Fiber Patch cord, MPO Patch cord

Use : FTTH, FTTX

Product name : MPO Fiber optic patch cord

Application : FTTB,40G/100G SFP,SFP+,QSFP, FTTH network

Connector Type : MPO

Fiber count : 8/12/24

Connector : MPO/MTP

Fiber Type : MM

Operating temperature : -40~+60

Contact Now

Product Description

MPO/MTP harnesses Breakout cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. With US Conec MTP connectors and Corning SMF-28 ultra optical fiber, it is optimized for 40G QSFP+ PLR4 to 10G SFP+ LR, 400G OSFP/QSFP-DD DR4 to 100G QSFP DR and 400G OSFP/QSFP-DD XDR4 to 100G QSFP FR optics direct connection and high-density data center applications. Fongko provide complete solution for your data center interconnection solution, including MPO/MTP Trunk Cable ,MPO/MTP Harnesses Cables ,MPO/MTP Fan out 0.9mm Patch Cords ,IP-Series MPO/MTP Assembly ,High Density Patch Cords ,MPO/MTP Loopback ,MT Patch Cords,MPO/MTP Cassettes ,MPO/MTP Fiber Optic Patch Panel;

Features

Insertion loss type available in Standard, Elite / Low Loss
Fiber count available in 8, 12, 24
MTP/MPO connector type available in Male, Female
Fiber type available in SM (G652D, G657A1, G657A2), MM (OM1, OM2, OM3, OM4)
Cable jacket type available in OFNR, LSZH, OFNP
Fanout length available in 0.5m, 1m, etc.
Multi-fiber connector type available in MTP, MPO with APC or PC polishing type
Single-fiber connector type available in LC, SC with APC or UPC polishing type

Application

Telecom system
Data Center
High Density Cabling Solution
MPO/MTP cassette

Single Mode 0.9mm lc MPO To SC Mtp Fanout Cable 0.5m 12 Fiber
